Zebra ZD620 User Manual

210
Print Operations
Using the Label Dispenser Option
The label dispenser option allows you to print a label and have the backing material
(liner/web) automatically removed. When printing multiple labels, removing the dispensed
(peeled) label triggers the printer to print and dispense the next label.
To use dispense-mode, set ‘Media Handling’ to ‘Peel-Off’ in the printer driver or with the
Zebra Setup Utility using the ‘Configure Printer Settings’ wizard. Otherwise, you must send
the ZPL programming commands to the printer.
When programming in ZPL, you can use the command sequences shown below to
configure the printer to use the dispenser option:
^XA ^MMP ^XZ
^XA ^JUS ^XZ
1. Load your labels into the printer. Close the printer and press the FEED button until a
minimum of 100 millimeters or 4 inches of exposed labels exit the printer. You can
leave the labels on the liner.

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
