PRINT MODE

Description: Select a print mode that is compatible with your printer options. For

information about how the print mode selections work with different printer options, see

PRINT MODE.

Accepted values: TEAR-OFF, PEEL-OFF, CUTTER

Related ZPL command(s): ^MM

SGD command used: media.printmode

Print Server web page: View and Modify Printer Settings

> General Setup >

Print Mode

SETTINGS

—

DARKNESS

—

PRINT SPEED

—

MEDIA TYPE

—

PRINT METHOD

—

TEAR OFF

—

PRINT WIDTH

—

PRINT MODE

—

LABEL TOP

—

LEFT POSITION

—

REPRINT MODE

—

LABEL LENGTH MAX

—

LANGUAGE
