Zebra ZD620 - WIRED MAC ADDRESS

To Next Page

To Previous Page

109

Printer Configuration Menus

WIRED MAC ADDRESS

Description: View the Media Access Control (MAC) address of the wired print server.

SGD command used: internal_wired.mac_addr

Printer Web page: View and Modify Printer Settings > Network Communications Setup >

TCP/IP Settings

NETWORK

—

ACTIVE PRINT SERVER

—

PRIMARY NETWORK

—

WIRED IP ADDRESS

—

WIRED SUBNET MASK

—

WIRED GATEWAY

—

WIRED IP PROTOCOL

—

WIRED MAC ADDRESS

—

WLAN IP ADDRESS

—

WLAN SUBNET MASK

—

WLAN GATEWAY

—

WLAN IP PROTOCOL

—

WLAN MAC ADDRESS

—

ESSID

—

CHANNEL

—

SIGNAL

—

IP PORT

—

IP ALTERNATE PORT

—

PRINT INFORMATION

—

RESET NETWORK

—

VISIBILITY AGENT

—

LOAD DEFAULTS
