142

Printer Configuration Menus

BT SPEC VERSION

Description: View the Bluetooth operational specification level.

SGD command used: bluetooth.radio_version

BLUETOOTH

—

BLUETOOTH ADDRESS

—

MODE

—

DISCOVERY

—

CONNECTED

—

BT SPEC VERSION

—

MIN SECURITY MODE
