32

Printer Features

Inside the ZD420 Ribbon Cartridge Printer

Movable Sensor

(Black Mark and Lower Web/Gap)

Media Guides

Head-Up Sensor

(inside)

Media Guide Stop

Adjustment

Platen (Drive) Roller

Roll Holders

Ribbon Cartridge

Shown Installed

(sold separately)

Upper Web (Gap)

Array Sensor

Release

Arms (2)

Ribbon Drive

Transport
