Zebra ZD620 User Manual

236
USB Host Port and Link-OS Demonstration Examples
Using the USB Hosts Port and the NFC Capabilities
The Zebra Print Touch ™ feature allows you to touch an Android ™ -based, Near Field
Communication (NFC)-enabled device such as a smart phone or tablet to the printer’s
Print Touch logo to pair the device to the printer. This capability allows you to use your
device to provide information for which you are prompted and then print a label using that
information.
Important • Some mobile devices may not support NFC communication with the printer
until you configure the required NFC settings in your device. If you encounter difficulties,
consult your service provider or your smart device manufacturer for more information.
Print Touch Location
(Passive NFC)

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
