Zebra ZD620 - VIRTUAL DEVICE

To Next Page

To Previous Page

129

Printer Configuration Menus

VIRTUAL DEVICE

Description: If any Link-OS Virtual Device apps are installed on your printer, you may

view or enable/disable them from this user menu. For more information about Virtual

Devices, go to the User Guide for the appropriate Virtual Device, or contact your local

reseller.
