44
Install Hardware Options
Installing the Internal Ethernet (LAN) Module
1. With the DC power plug and module’s access door removed, slide the Ethernet
module into the printer. Push the circuit card in slowly but firmly until the card is just
past the inside lip of the access door.
2. Align the bottom of the Ethernet port’s door cover to the bottom lip of the module
access opening. Swing the door up and snap the cover closed.
Note For best printer performance, update the printer’s firmware after installing options
or immediately after the printer’s initial setup. See Updating Printer Firmware.
Ethernet Port (RJ-45)
