Printer Configuration Menus

MEDIA/RIBBON CAL

Description: Calibrate the printer to adjust the sensitivity of the media sensors.

Related ZPL command(s): ~JC

SGD command used: ezpl.manual_calibration

Print Server web page: The calibration procedure cannot be initiated through the web

pages.

TOOLS

—

PRINT INFORMATION

—

IDLE DISPLAY

—

POWER UP ACTION

—

HEAD CLOSE ACTION

—

LOAD DEFAULTS

—

MEDIA/RIBBON CAL

—

DIAGNOSTIC MODE

—

ZBI ENABLED?

—

RUN ZBI PROGRAM

—

STOP ZBI PROGRAM

—

CONFIG INFO TO USB

—

PRINT USB FILE

—

COPY USB FILE TO E:

—

STORE E: FILE TO USB

—

PRINT STATION

—

PASSWORD PROTECT

—

PRINT TEST FORMAT
