Printer Features

Inside the ZD620 and ZD420 Direct Thermal Printers

Movable Sensor

(Black Mark and Lower Web/Gap)

Media Guides

Head-Up Sensor

(inside)

Media Guide Stop

Adjustment

Platen (Drive) Roller

Roll Holders

Upper Web (Gap)

Array Sensor

Printhead

Media Dancer

(ZD620 Only)
