Printer Features

Printer Power Supply Options

ZD-Series printers offer field installable attached power options: an attached power supply

base or a battery power base (available in Q2 2018). These options easily attach with

screws and replace the power supply that was included with your printer.

Attached Power Supply Base

Battery Power Base and Power Pack

Attached Power

Supply Base

Battery Power Base

(artist rendering)

Battery Power Base

and Accessories

available after Q2 2018
