PRINT METHOD

Description: Specify if the printer needs to use ribbon for printing.

Accepted values:

THERMALTRANS—Uses ribbon and thermal transfer media.

DIRECTTHERMAL—Uses direct thermal media and no ribbon.

Related ZPL command(s): ^MT

SGD command used: ezpl.print_method

Print Server web page: View and Modify Printer Settings

> General Setup >

Print Method
