Printer Configuration Menus

ZBI ENABLED?

Description: Zebra Basic Interpreter (ZBI 2.0™) is a programming option that may be

purchased for your printer. If you would like to purchase this option, contact your Zebra

reseller for more information.

Accepted values: NO or YES

SGD command used: zbi.key (identifies if the ZBI 2.0 option is enabled or disabled on

the printer)

Print Server web page: NotApplicable
