LABEL SENSOR

Description: Set the sensitivity of the label sensor.

Important • This value is set during sensor calibration. Do not change this setting unless you

are told to do so by Zebra Technical Support or by an authorized service technician.

Acceptable values: 0

to 255

SGD command used: ezpl.label_sensor

Print Server web page: ViewandModifyPrinterSettings>Calibration
