Zebra ZD620 User Manual

121
Printer Configuration Menus
VISIBILITY AGENT
Description: When the printer is connected to a wired or wireless network, it will attempt
to connect to Zebra’s Asset Visibility Service via the Cloud-based Zebra Printer Connector
using an encrypted, certificate-authenticated web socket connection. The printer sends
Discovery Data and Settings and Alerts Data. Data printed via any label formats is NOT
transmitted.
To opt out of this feature, disable this setting. For more information, see the “Opting Out of
the Asset Visibility Agent” application note at http://www.zebra.com
.
Accepted values: ON or OFF
SGD command used: weblink.zebra_connector.enable
Printer Web page: View and Modify Printer Settings > Network Configuration >
Cloud Connect Settings
NETWORK
—
ACTIVE PRINT SERVER
—
PRIMARY NETWORK
—
WIRED IP ADDRESS
—
WIRED SUBNET MASK
—
WIRED GATEWAY
—
WIRED IP PROTOCOL
—
WIRED MAC ADDRESS
—
WLAN IP ADDRESS
—
WLAN SUBNET MASK
—
WLAN GATEWAY
—
WLAN IP PROTOCOL
—
WLAN MAC ADDRESS
—
ESSID
—
CHANNEL
—
SIGNAL
—
IP PORT
—
IP ALTERNATE PORT
—
PRINT INFORMATION
—
RESET NETWORK
—
VISIBILITY AGENT
—
LOAD DEFAULTS

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
