139

Printer Configuration Menus

MODE

Description: View the Bluetooth connection pair printer’s device type—Slave (typical) or

Master.

BLUETOOTH

—

BLUETOOTH ADDRESS

—

MODE

—

DISCOVERY

—

CONNECTED

—

BT SPEC VERSION

—

MIN SECURITY MODE
