Controls and Indicators

Status - Bluetooth Low Energy (BTLE) Option

Bluetooth LE Paired

Bluetooth Low Energy has paired.

Bluetooth LE Failed to Pair

Bluetooth Low Energy has failed to pair.

Status - Ethernet (LAN) Option

Ethernet (LAN) No Link

No Ethernet link is available. NETWORK status is

light off

Ethernet (LAN) 100base Link

A 100 Base link was found.

Ethernet (LAN) 10base Link

A 10 Base link was found.

Ethernet (LAN) Link Error

An error condition exists. The printer is not

connected to your network.
