Zebra ZD620 - Upper Half of ZD620 ZD420 Direct Thermal Printers; Upper Half of ZD620420 Thermal Transfer Printers

247
Maintenance
Upper Half of ZD620/ZD420 Direct Thermal Printers
1. Wipe the areas (outlined in orange) to remove adhesive and other contaminants. Do
not clean the sensor array.
Upper Half of ZD620/420 Thermal Transfer Printers
1. Wipe the area (outlined in orange) near the printhead on the front of the ribbon
carriage.
Don’t Clean Sensor
