Printer Configuration Menus

REPRINT MODE

Description: When reprint mode is enabled, you can reprint the last label printed by

pressing FEED button.

Accepted values: ON or OFF(default)

Related ZPL command(s): ^JZ

SGD command used: zpl.left_position

Print Server web page: Notsupportedatthistime

SETTINGS

—

DARKNESS

—

PRINT SPEED

—

MEDIA TYPE

—

PRINT METHOD

—

TEAR OFF

—

PRINT WIDTH

—

PRINT MODE

—

LABEL TOP

—

LEFT POSITION

—

REPRINT MODE

—

LABEL LENGTH MAX

—

LANGUAGE
