Zebra ZD620 User Manual

68
Controls and Indicators
Display Controls and Menus
ZD620 printer’s with the LCD User Interface provides the user printer status and a menu
system to configure the printer and run internal utilities. The printer is capable of displaying
messages in multiple languages.
The printer’s default screen information is shown.
• The top line displays printer model information.
• The center area shows printer status information (customizable) and pop-up
messages.
• The two (2) bottom lines show the printer’s Firmware version and the printer’s IP
Address by default. This area can be customized to show different, user
selectable information. See IDLE DISPLAY for a more information.
• The bottom area below the white line are for Action items.
Z
EBRA
ZD620
PRINTER READY
V84.20.05ZP37288
168.192.0.1

Zebra ZD620 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Flash memory	512 MB
Internal memory	256 MB
Number of fonts	16
Built-in barcodes	1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Page description languages	EPL2, XML, ZBI, ZPL II
Display	LCD
Color display	Yes
Product color	Black, Grey
Display resolution	320 x 240 pixels
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Mobile operating systems supported	Android, iOS
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	4.4 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.08 - 0.1905 mm
Maximum label length	0.991 m
Maximum roll diameter	127 mm

Weight and Dimensions

Depth	221 mm
Width	177 mm
Height	151 mm
