134

Printer Configuration Menus

DATA BITS

Description: Select the data bits value that matches the one being used by the host

computer.

Acceptable values: 7

or 8

Related ZPL command(s): ^SC

SGD command used: comm.data_bits

Print Server web page: ViewandModifyPrinterSettings>

Serial Communications Setup

PORTS

—

BAUD RATE

—

DATA BITS

—

PARITY

—

HOST HANDSHAKE

—
