141

Printer Configuration Menus

CONNECTED

Description: View the Bluetooth connection status to its paired device (Yes or No).

BLUETOOTH

—

BLUETOOTH ADDRESS

—

MODE

—

DISCOVERY

—

CONNECTED

—

BT SPEC VERSION

—

MIN SECURITY MODE
