Printer Configuration Menus

IP PORT

Description: This printer setting refers to the internal wired print servers port number that

the TCP print service is listening on. Normal TCP communications from the host should be

directed to this port.

SGD command used: internal_wired.ip.port

Printer Web page: View and Modify Printer Settings > Network Communications Setup >

TCP/IP Settings

NETWORK

—

ACTIVE PRINT SERVER

—

PRIMARY NETWORK

—

WIRED IP ADDRESS

—

WIRED SUBNET MASK

—

WIRED GATEWAY

—

WIRED IP PROTOCOL

—

WIRED MAC ADDRESS

—

WLAN IP ADDRESS

—

WLAN SUBNET MASK

—

WLAN GATEWAY

—

WLAN IP PROTOCOL

—

WLAN MAC ADDRESS

—

ESSID

—

CHANNEL

—

SIGNAL

—

IP PORT

—

IP ALTERNATE PORT

—

PRINT INFORMATION

—

RESET NETWORK

—

VISIBILITY AGENT

—

LOAD DEFAULTS
