DISCOVERY

Description: Select if the printer is “Discoverable” for Bluetooth device pairing.

Acceptable values:

• ON—Enables Bluetooth discoverable mode.

• OFF—Disables Bluetooth discoverable mode.

SGD command used: bluetooth.discoverable

BLUETOOTH

—

BLUETOOTH ADDRESS

—

MODE

—

DISCOVERY

—

CONNECTED

—

BT SPEC VERSION

—

MIN SECURITY MODE
