224

Print Operations

4. Reinstall the connectivity module and module access door. See Installing the Internal

Ethernet (LAN) Module or Installing the Serial Port Module for ZD420 printer models.

The connectivity module on a ZD620 printer model is installed like a ZD420 printer’s

module.

5. Reconnect the printer DC power plug and interface cables to the printer.
