254

Maintenance

Cleaning Ribbon Cartridge Sensor

4. Ribbon Cartridge Sensor Pins - Only clean when the cartridges are failing

detection. Clean the Ribbon Cartridge interface pins with a gentle wiping from right to

left. Up and down motions may damage the pins.

Ribbon Cartridge

Sensor

Contact Pins
