Maintenance
3. Swing the loose right side of the printhead out of the printer. Pull it out and to the right
a little to get the left side of the printhead clear. Pull the printhead out and free of the
top cover to gain access to its attached cables on the backside of the printhead. Note,
the red highlights the left side printhead retainer slot.
4. Gently but firmly pull the two printhead cable bundle connectors off of the printhead.
Pull the ground wire off the printhead.
Printhead Assembly
Connectors
Printhead Ground Wire
To Next Page
