Zebra ZD620 - Page 52

52
Install Hardware Options
4. Insert a screw in the bottom adapter mounting hole. Pinch the adapter tightly to the
roll holder while tightening the screw. Tighten the screw until there is no gap between
the adapter and roll holder. Do not tighten beyond this point. Over tightening will strip
the thread.
5. Repeat step 1-4 for the other adapter and roll holder.
Example of Label Roll
with 76.2 mm (3.0
inch) Inner Core
mounted on Media
Core Adapters
