Chapter 5 Web Interface Tutorials
AX/DX/EX/PX Series User’s Guide
100
5.3.4 Setting Up Two Guest WiFi Networks on Different WiFi Bands
In this example, a company wants to create two Guest WiFi networks: one for the Guest group and the
other for the VIP group as shown in the following figure. Each network will have its SSID and security
mode to access the internet.
• The Guest group will use the 2.4G band.
• The VIP group will use the 5G band.
The Company will use the following parameters to set up the WiFi network groups.
1 Go to the Wireless > General screen and set Band to 2.4GHz to configure 2.4G Guest WiFi settings for
Guest. Click Apply.
Note: You will not be able to configure the 2.4G and 5G Guest WiFi settings separately if Keep
the same settings for 2.4G and 5G wireless network is enabled.
Table 25 WiFi Settings Parameters Example
BAND 2.4G 5G
SSID Guest VIP
Security Mode WPA3-SAE/WPA2-PSK WPA3-SAE/WPA2-PSK
Pre-Shared Key guest123 123456789
