Chapter 5 Web Interface Tutorials

AX/DX/EX/PX Series User’s Guide

121

5.5.3 Configuring a MAC Address Filter for Wired LAN Connections

You can use a MAC address filter to exclusively allow or permanently block someone from the wired

LAN network.

This example shows that computer B is not allowed access to the wired LAN network.
