Chapter 12 Quality of Service (QoS)
AX/DX/EX/PX Series User’s Guide
323
The following table describes the labels in this screen.
12.7.1 Add or Edit a QoS Policer
Click Add New Policer in the Policer Setup screen or the Edit icon next to a policer to show the following
screen.
Table 94 Network Setting > QoS > Policer Setup
LABEL DESCRIPTION
Add New
Policer
Click this to create a new entry.
# This is the index number of the entry.
Status This field displays whether the policer is active or not. A yellow bulb signifies that this policer is
active. A gray bulb signifies that this policer is not active.
Name This field displays the descriptive name of this policer.
Regulated
Classes
This field displays the name of a QoS classifier
Meter Type This field displays the type of QoS metering algorithm used in this policer.
Rule These are the rates and burst sizes against which the policer checks the traffic of the member
QoS classes.
Action This shows how the policer has the Zyxel Device treat different types of traffic belonging to the
policer’s member QoS classes.
Modify Click the Edit icon to edit the policer.
Click the Delete icon to delete an existing policer. Note that subsequent rules move up by one
when you take this action.
