Chapter 10 Home Networking

AX/DX/EX/PX Series User’s Guide

293

10.11.1 Auto-discover Your UPnP-enabled Network Device

Before you follow these steps, make sure you already have UPnP activated on the Zyxel Device and in

your computer.

Make sure your computer is connected to the LAN port of the Zyxel Device.

1 Open File Explorer and click Network.

2 Right-click the Zyxel Device icon and select Properties.
