Chapter 12 Quality of Service (QoS)
AX/DX/EX/PX Series User’s Guide
321
12.6 QoS Shaper Setup
This screen lets you use the token bucket algorithm to allow a certain amount of large bursts of traffic
while keeping most outgoing traffic at the average rate. Click Network Setting > QoS > Shaper Setup.
The screen appears as shown.
Figure 163 Network Setting > QoS > Shaper Setup
The following table describes the labels in this screen.
To Queue Index Select a queue that applies to this class.
You should have configured a queue in the Queue Setup screen already.
Cancel Click Cancel to exit this screen without saving any changes.
OK Click OK to save your changes.
Table 91 Network Setting > QoS > Classification Setup > Add New Classification/Edit (continued)
LABEL DESCRIPTION
Table 92 Network Setting > QoS > Shaper Setup
LABEL DESCRIPTION
Add New
Shaper
Click this to create a new entry.
# This is the index number of the entry.
Status This field displays whether the shaper is active or not. A yellow bulb signifies that this policer is
active. A gray bulb signifies that this shaper is not active.
Interface This shows the name of the Zyxel Device's interface through which traffic in this shaper applies.
Rate Limit This shows the average rate limit of traffic bursts for this shaper.
Modify Click the Edit icon to edit the shaper.
Click the Delete icon to delete an existing shaper. Note that subsequent rules move up by one
when you take this action.
To Next Page
