Chapter 15 IGMP/MLD

AX/DX/EX/PX Series User’s Guide

356

Note: Some models might only support IGMP/MLD Default Version configuration.

Figure 187 Network Setting > IGMP/MLD

The following table describes the labels in this screen.

Table 115 Network Setting > IGMP/MLD

LABEL DESCRIPTION

IGMP/MLD Configuration

Default Version Enter the version of IGMP (1~3) and MLD (1~2) that you want the Zyxel Device to use on the

WAN.
