Chapter 2 Hardware
AX/DX/EX/PX Series User’s Guide
41
Internet Green On The Zyxel Device has an IP connection but no traffic.
Your device has a WAN IP address (either static or assigned by a
DHCP server), PPP negotiation was successfully completed (if used)
and the DSL connection is up.
Blinking The Zyxel Device is sending or receiving IP traffic.
Off There is no Internet connection or the gateway is in bridged mode.
Red On The Zyxel Device attempted to make an IP connection but failed.
Possible causes are no response from a DHCP server, no PPPoE
response, PPPoE authentication failed.
LAN1 – 4 Green On The Zyxel Device has a successful 10/100/1000 Mbps Ethernet
connection with a device on the Local Area Network (LAN).
Blinking The Zyxel Device is sending or receiving data to/from the LAN at 10/
100/1000 Mbps.
Off The Zyxel Device does not have an Ethernet connection with the LAN.
2.4G WLAN/
WPS
Green On The 2.4 GHz WiFi network is activated.
Blinking The Zyxel Device is communicating with 2.4 GHz WiFi clients.
Amber On The WPS process fails.
Blinking The Zyxel Device is setting up a WPS connection with a 2.4 GHz WiFi
client.
Off The 2.4 GHz WiFi network is not activated.
5G WLAN/
WPS
Green On The 5 GHz WiFi network is activated.
Blinking The Zyxel Device is communicating with 5 GHz WiFi clients.
Amber On The WPS process fails.
Blinking The Zyxel Device is setting up a WPS connection with a 5 GHz WiFi
client.
Off The 5 GHz WiFi network is not activated.
Phone1,
Phone2
Green On A SIP account is registered for at least one phone port, and there is no
voice message in the corresponding SIP account.
Blinking A telephone connected to one of the phone port has its receiver off
the hook or there is an incoming call. There is no voice message in the
corresponding SIP account.
Amber On A SIP account is registered for the phone port and there is a voice
message in the corresponding SIP account.
Blinking A telephone connected to the phone port has its receiver off the
hook or there is an incoming call. There’s voice message in the
corresponding SIP account.
Table 10 LED Descriptions (DX5401-B0/B1 and EX5401-B0/B1) (continued)
LED COLOR STATUS DESCRIPTION
