Chapter 30 Routing Table

AX/DX/EX/PX Series User’s Guide

456

Figure 253 System Monitor > Routing Table

The following table describes the labels in this screen.

Table 173 System Monitor > Routing Table

LABEL DESCRIPTION

IPv4 / IPv6 Routing Table

Destination This indicates the destination IPv4 address or IPv6 address and prefix of this route.

Gateway This indicates the IPv4 address or IPv6 address of the gateway that helps forward this route’s

traffic.

Subnet Mask This indicates the destination subnet mask of the IPv4 route.
