Chapter 44 Diagnostic
AX/DX/EX/PX Series User’s Guide
503
Figure 289 Maintenance > Diagnostic > OAM Ping
The following table describes the labels in this screen.
Table 195 Maintenance > Diagnostics > OAM Ping
LABEL DESCRIPTION
Select a PVC on which you want to perform the loopback test.
F4 segment Press this to perform an OAM F4 segment loopback test.
F4 end-end Press this to perform an OAM F4 end-to-end loopback test.
F5 segment Press this to perform an OAM F5 segment loopback test.
F5 end-end Press this to perform an OAM F5 end-to-end loopback test.
