Chapter 59 System
GS2220 Series User’s Guide
461
The following table describes the labels in this screen.
59.3 G e ne ra l Se tup
Use this screen to configure general settings such as the system name and time. Click Syste m > G e ne ra l
Se tup in the navigation panel to display the screen as shown.
Table 242 System > System Information
LABEL DESC RIPTIO N
System Name This field displays the descriptive name of the Switch for identification purposes.
Product Model This field displays the product model of the Switch. Use this information when searching for
firmware upgrade or looking for other support information in the website.
ZyNOS F/W
Version
This field displays the version number of the Switch 's current firmware including the creation date.
Ethernet
Address
This field refers to the Ethernet MAC (Media Access Control) address of the Switch.
CPU Utilization
Current (%)
CPU utilization quantifies how busy the system is. Curre nt (% ) displays the current percentage of
CPU utilization.
Memory
Utilization
Memory utilization shows how much DRAM memory is available and in use. It also displays the
current percentage of memory utilization.
Name This field displays the name of memory pool.
Total (byte) This field displays the total number of bytes in this memory pool.
Used (byte) This field displays the number of bytes being used in this memory pool.
Utilization
(%)
This field displays the percentage (%) of memory being used in this memory pool.
Hardware Monitor
Temperature
Unit
The Switch has temperature sensors that are capable of detecting and reporting if the
temperature rises above the threshold. You may choose the temperature unit (Centigrade or
Fahrenheit) in this field.
Temperature
(C)
BO ARD/MAC /PHY (PO WER – for GS2220-10HP only) refers to the location of the temperature
sensor on the Switch printed circuit board.
Status This field displays Norma l for temperatures below the threshold and Erro r for those above.
Current This shows the current temperature at this sensor.
MAX This field displays the maximum temperature measured at this sensor.
MIN This field displays the minimum temperature measured at this sensor.
Threshold This field displays the upper temperature limit at this sensor.
