6166 DC Vol
tage Current S
ource Operation Manu
al
8.3.1 Remo
te Calibration Procedures
8-8
NOTE:
The calibration
must includ
e zero point c
alibration,
+ full scal
e calibration
and -
full scale ca
libration.
Range
Mi
nimum resolution
Neces
sary minimum r
esolution
10 mV
10 nV
1 nV
100 mV
100 nV
10 nV
1000 m
V
1
V
100
nV
Figure 8-6 Remote Calibratio
n Procedure
(Divider V
oltage Source)
229
231
