Startup
7
PN 4004700–ENG Rev. K
Most of the functionality of the display is not available until the basic setup process is completed.
Complete these initial configuration steps for the Run Time Environment to be active:
• Equipment Operating Configuration.
Access Configuration Setup by pressing or pressing an app specific to a field operation.
• Product setup.
• Start Field Operation.
Status Indicators
Status Indicators are used to show different states of external equipment
connected to the display (for example: , , and ) and provides easy access to
data transfer and diagnostic features of the display.
AgFiniti Status Indicators
Connected to hotspot/network with active internet and AgFiniti connection.
•Display is ready for use with AgFiniti.
Connected to hotspot/network with internet connection, but not logged into AgFiniti.
•Verify AgFiniti login credentials have been entered properly.
•Default status when not using AgFiniti but display is connected to the internet (NTRIP RTK on InCommand).
Connected to hotspot/network with no internet connection.
•Verify hotspot has active internet connectivity.
Display has a stored hotspot/network connection but no active internet, hotspot, or AgFiniti connection.
•Verify WiFi adapter is plugged into the back of the display.
•Will only populate after a hotspot/network has saved in the display.
AgFiniti® Status Indicator
Devices Status Indicator
Satellites Status Indicator
GNSS
Remote Support
CAN
Operator
Data Transfer
