22
Display Setup
The Display screen contains the following tabs:
• General tab — Displays settings related to time, date, display screen settings, operating units, enabling video input,
and ISOBUS settings. For ISOUBUS settings “ISOBUS Settings” on page 25.
• Display tab — Setting up and make any needed edits to the owner personal information.
• Features tab — Lists unlocks for display.
• AgFiniti tab — Access AgFiniti account settings and options. See “AgFiniti®” on page 35.
• Advanced tab — Includes information related to log files and system backups. See “Display Backups” on page 33.
Features tab
Unlocking Features
The Features tab is used to enter unlock codes.
Unlock codes are unique to the serial number of
each display and the feature registration
number. Supply these numbers to dealer when
purchasing unlock codes.
Press to enter the unlock code and
press to enable the feature.
÷
NOTE!: Once a feature is unlocked, that
feature remains with that display and
cannot be transferred to another.
Advanced tab
The tab allows to specify:
• Settings for copying log files.
• Specify Key Switch Standby settings.
• View and manually upgrade module firmware.
• Create and restore backup files.
±
WARNING!: The Export Diagnostic Files, Advanced Parameters, Copy Debug Files, Clear Debug Files and Service
Mode functionality on the Advanced tab is reserved for use by the manufacturer. DO NOT change any of these
settings without specific instruction from the manufacturer.
Key Switch Standby
Console Setup
General
Automatic Swath Control
Multiple Product
Norac UC5 Interface
ISOBUS
HARDI Sprayer
Enabled
Enabled
Enabled
Enabled
Enabled
Display
Features
AgFiniti
Advanced
Unlock
Feature Description:
