Field Operations
67
PN 4004700–ENG Rev. K
Disable/Enable Heading Detection
With Heading Detection disabled, the icon will always follow the GPS heading. When using a Harvest configuration,
Heading Detection is automatically disabled regardless of the state of the enable/disable button.
Vehicle Icon
Master Switch Status
This button shows if the Master Switch is on or off. It is toggled by a master switch or a switch box.
(O) AutoSwath button—turns the AutoSwath feature on and off.
(P) Logging button
AutoSteer button
The Engage icon status of the AutoSteer system. The appearance of this icon displays the following:
Vehicle Icon—When Zoomed Out—This gold colored triangle indicates the display is in zoom to
extent mode. When in North Oriented View the vehicle implement does not appear but logged data will
still populate on the map.
Vehicle Icon—logging—If the vehicle is logging, the implement icon appears as a green bar behind it.
Vehicle Icon—logging (with all sections ON)—If the vehicle is logging data from an implement split
into sections, (for instance during a planting or application operation), then these sections appear in the
implement icon.
Vehicle Icon—not logging—If the vehicle is not logging data, then the implement icon appears as a
grey bar.
Vehicle Icon—Master Switch Off—When the master switch is off the vehicle will show a thinner red
bar.
Master Switch Status - ON (GREEN) Master Switch Status - OFF (RED)
AutoSwath - ON AutoSwath - OFF
Logging - ON Logging - OFF
AutoSteer is ON and
ready to use.
AutoSteer is OFF but
ready to engage.
AutoSteer is OFF and
unable to engage.
