Network Diagnostics
or
Network Diagnostics shows users network status
via color indicators below.
Light status
÷
NOTE!: Refer to the text to the right of the
diagnostic lights for additional
information on status.
DisplayCast Statistics
As each display syncs with AgFiniti Cloud, the
statistics page will update to reflect the
information below. (This can be used to
troubleshoot data sync issues.)
• This Display Last Updated – Timestamp of
most recent data sync from AgFiniti Cloud to
current display.
• AgFiniti Last Updated – Timestamp of most
recent data sync to AgFiniti Cloud from any
display.
• Other Displays – Lists any displays logged
into AgFiniti by serial number and active
configuration.
• Position Update – Timestamp of last
received GPS position for that display.
• Current Heartbeat – Live Stat information
sent to the AgFiniti cloud.
Green-connected (Working Properly)
Yellow-checking status
Red-Needs attention
DisplayCast
Data Transfer
Networking
Diagnostics
Wireless adapter connected
Connection to hotspot/access point
Internet connection
AgFiniti connection
Connected
Connected
Connected
Connected
Advanced Diagnostics
Network Diagnostics
DisplayCast
Statistics
This Display Last Updated:
DisplayCast Statistics
AgFiniti Last Updated:
03/28/2017 11:10:23 AM
03/28/2017 11:13:50 AM
Other Displays:
2420010043: Display A
Position Update: 11:14:28 AM
Current Heartbeat
