Operation 9960 Self-Propelled Peanut Combine
96 06/03/05 MAN091
Pre-operation Checking
3. Check hydrostatic/hydraulic oil level with
header on ground and all cylinders
retracted (top photo). Oil must cover sight
class A and be below top of sight class B.
Add oil if needed but do not overfill.
4. With the engine off, check the hydraulic oil
at the engine gear case. Make sure the
oil is not below the “LOW” mark on the
dipstick but do not overfill it (bottom
photo).
dipstick
