Monitors 9960 Self-Propelled Peanut Combine
88 06/03/05 MAN091
Header Calibration
5. Establish the sensor minimum setting by
lowering and tilting the header raise/lower
switch (Fig. 1; A) until the wheels contact
the ground. The left- and right-hand
wheels of the header should contact the
ground at the same time as the header is
lowered.
6. Press the calibration switch (fig. 3). Hdr
and H-UP display on the tachometer.
Fig 1
Fig 2
Fig 3
this position, an error code displays. If this
occurs, you need to restart this procedure
and adjust the position slightly higher or
lower
until the combine accepts it. If you
cannot find an acceptable height, reset the
gauge wheels and redo the calibration
procedure.
