Chapter 8
8.3 Main GUI
Start/Stop M Start/Stop measurement
Search hardware F2 Search for newly added hardware
Controller standby Force the controller to go into standby mode
Controller reboot Reboot the controller
Quit Q Quit DTrack2
Settings Shortcut page 146
Cameras F7 Camera settings (e.g. flash intensities, syncgroup as-
signment)
Synccard Synccard settings (e.g. tracking frequency, external
synchronisation)
Inertial Sensor Settings for inertial sensors
ART Radio Info Settings for ART radio transceivers and devices within
your setup
Tracking Activate 3DOF calculation, automatic start of measure-
ment
Body Administration F8 General settings for all targets and interaction devices
Output F9 Set output channels and configure the data to be trans-
mitted
Fingertracking Configure your Fingertracking (incl. tactile feedback)
device
Flystick Configure your Flystick
Measurement Tool Configure your Measurement Tool
Controller Configure the IP and NTP settings of your controller
Cascaded System Configure a Cascaded System with available con-
trollers
Calibration Shortcut page 165
Start static reflex scan for all
enabled cameras
Starts the static reflex scan
Inertial Sensor Calibration Re-calibrate the drift correction of the inertial sensor
Room F5 Room calibration
Room adjustment Shift + F5 Adjust / transform the room coordinate system
Body F6 Body calibration
Body adjustment Shift + F6 Adjust / transform the body coordinate system
Hybrid Body Determine the relative rotation between optical and in-
ertial sensor (i.e. run hand-eye calibration)
Fingertracking Start calibration process for Fingertracking (i.e. hand
geometry)
Measurement Tool Start tip calibration process for the Measurement Tool
Display Shortcut page 187
Monitor 2DOF Graphical display of markers recognized by the cam-
eras
Data F10 Display measurement results (6DOF and / or 3DOF)
Fingertracking Display Fingertracking measurement data
Flystick Display Flystick measurement data
Measurement Tool Display Measurement Tool data
Events Display event messages generated by DTrack2
133
