A Technical specifications
Dimensions camera body
Length 55mm
Width 100mm
Height 100mm
Weight 540g
A.1.3 TRACKPACK/E
IR Source
invisible IR 850nm
flash intensity adjustable in 100 steps
Performance
Sensor resolution 1.1 MPixels
Frame rate up to 120 Hz
Field of view (FoV)
Lens Camera mode
Resolution Medium Speed
1.1 MPix 0.7 MPix 0.5 MPix
60 Hz 90 Hz 120 Hz
F = 3.5mm FoV (horizontal x vertical) 97
◦
× 79
◦
97
◦
× 51
◦
97
◦
× 36
◦
Max. tracking range
(12mm markers)
4.5m 4.5m 4.5m
Connectivity & Power Supply
single cable solution via Gigabit Ethernet, RJ45, PoE (IEEE 802.3af Standard)
max. cable length 100m
Voltage 44 - 57 V (defined by the Standard)
max. power consumption 5 W
Protection category III
Interface connectors RJ45 (hosts data, synchronization and power)
Operating conditions
Temperature 0 .. 38
◦
C
Relative humidity 5 .. 50% (non-condensing)
Cooling system passive
Dimensions
Length 103 mm
Width 70 mm
Height 59 mm
Weight 0.51 kg
238
