A Technical specifications
Operating temperature 0 .. 38
◦
C
Relative humidity 5 .. 50%, non-condensing
Hazard notes for service personnel:
Risk of explosion if the mainboard battery is incorrectly replaced. Re-
place only with the same or from manufacturer recommended similar
type.
In order to replace a main fuse of the ART Controller always unplug the
power cord. Two main fuses are existing since two power supplies are
installed. So the device is possibly still under power although a fuse
has blown.
A.6 Overall system
System parameters
number of cameras 2 - 50 (max. 16 for TRACKPACK/E and TRACKPACK systems
(discontinued)
max. number of targets 50
max. number of hands 4
max. number of Flysticks
- Flystick2 5
- Flystick3 1
Scalability ARTTRACK system: fully scalable (2 - 50 cameras)
TRACKPACK/E and TRACKPACK systems (discontinued):
cascadable up to 16 cameras (additional controller necessary)
Accuracy
- of the timestamp with a Synccard2/3: ∆t
err
∼ ±0.01ms
with a SynccardTP: ∆t
err
∼ ±0.5ms
with a 3-Space wired inertial sensor: ∆t
err
∼ ±0.1ms
Operating conditions
Temperature 0 .. 38
◦
C
Relative humidity 5 .. 50%, non-condensing
Compatible shutter glasses
NuVision APG6000 ×
NuVision APG6100 ×
NVidia 3D Vision Pro ×, radio synchronization
RealD CE1 ×
RealD CE2 ×
RealD CE3 ×
RealD CE4 -
RealD CE5 ×
Volfoni EDGE ×, with Volfoni or NuVision Long-Range Emitter
XPand X103 ×, with NuVision Long-Range Emitter
XPand X101 ×
