A Technical specifications
Z
The specifications are subject to change without notice.
A.1 Cameras
A.1.1 ARTTRACK5
IR Source
invisible IR 850nm
flash intensity adjustable in 100 steps
Performance
Sensor resolution 1.3 MPixels
Frame rate up to 300 Hz
Field of view (FoV)
Lens Camera mode
Resolution Medium Speed
1.3 MPix 0.8 MPix 0.5 MPix
150 Hz 240 Hz 300 Hz
F = 3.5mm FoV (horizontal x vertical) 98
◦
× 77
◦
77
◦
× 57
◦
60
◦
× 44
◦
Max. tracking range
(12mm markers)
5.5m 5.5m 5.5m
F = 4.5mm FoV (horizontal x vertical) 75
◦
× 60
◦
60
◦
× 45
◦
47
◦
× 35
◦
Max. tracking range
(12mm markers)
6.3m 6.3m 6.3m
F = 6.0mm FoV (horizontal x vertical) 54
◦
× 44
◦
44
◦
× 33
◦
34
◦
× 26
◦
Max. tracking range
(12mm markers)
7.5m 7.5m 7.5m
Connectivity & Power Supply
single cable solution via Gigabit Ethernet, RJ45, PoE+ (IEEE 802.3at Standard)
max. cable length 100m
Voltage 44 - 57 V (defined by the Standard)
max. power consumption 17 W
Protection category III
Interface connectors RJ45 (hosts data, synchronization and power)
Operating conditions
Temperature 0 .. 38
◦
C
