Chapter 4
4.7 TRACKPACK/C (discontinued)
Please refer to chapter 5.3 on page 63 for more information.
4.7 TRACKPACK/C (discontinued)
Keep a distance of min. 20 cm when operating the camera ! The
camera is assigned to the Exempt Group according to IEC62471-1 and
therefore poses no risk or hazard to the human eye or skin at this dis-
tance.
Description The TRACKPACK system may also be combined with the TRACKPACK/C cam-
era in order to realize tracking in multi-sided projection environments (e.g. CAVE
R
, I-
Space). In such an environment it is necessary to drill holes into the projections’ corners
as the camera cannot see through the screen. The TRACKPACK/C camera has been
designed to easily fit into such holes by separating the lens from the electronics part (see
figure 4.10).
With its 3.5 mm lens a large field of view (FoV) is covered. Refer to A.1 on page 236 for
the respective FoV.
Figure 4.10: Camera TRACKPACK/C
The TRACKPACK system either consists of TRACKPACK/C cameras or it can be mixed
with standard TRACKPACK cameras - both variants are limited to a total number of four
cameras per system and come with a TRACKPACK Controller.
45
